HAMPTON

HAMPTON

0.00
Add To Cart

COLORS

DECORS

DIMENSIONS & FINISHES
Color Size Availability Thickness Finish
WHITE 4 X 12, 12 X 12, 12 X 24, 24 X 24 10mm NATURAL
GREY 4 X 12, 12 X 12, 12 X 24, 24 X 24 10mm NATURAL
TECHNICAL INFO

Reference standard Test method Reference value Declared value
CALIBER RANGE - Rectified ASTM C499 ± 0.25% or 0.03 in (0.8 mm) 1 ± 0.20%
THICKNESS 2 ASTM C499 Range: ± 0.04 inch (1.02 mm) COMPLIANT
WEDGING - Rectified ASTM C502 ± 0.25% or 0.03 in (0.8 mm) 1 ± 0.15%
WARPAGE EDGE - Rectified ASTM C485 ± 0.40% or 0.05 in (1.3 mm) 3 or 1.8 mm 4 ±0.25%
BREAKING STRENGTH ASTM C648 Average ≥ 250 lbf. (1.11 kN)/ Individual ≥ 225 lbf. (1.00 kN) COMPLIANT
WATER ABSORPTION ASTM C373 ≤ 0.50% COMPLIANT
THERMAL SHOCK 5 ASTM C484 PASS PASS
RESISTANCE TO FREEZE/TAW CYCLING 6 ASTM C1026 AS REPORTED NO DAMAGE
VISIBLE ABRASION RESISTANCE 5 ASTM C1027- 99 AS REPORTED IV – V
CHEMICAL RESISTANCE ASTM C650 AS REPORTED NOT AFFECTED
STAIN RESISTANCE ASTM C1378 CTI81-7D AS REPORTED NOT AFFECTED
DINAMIC COEFFICIENT OF FRICTION section 9.6 0.42 7 Dry 0.72* Wet 0.61*
