COLORS
DECOR
DIMENSIONS
| Color | Size Availability | Thickness | Finish |
| Freedom White | 12 x 24, 24 x 24, 24 x 48, 12 x 12 Mosaic A | 9mm and 20mm (24 x 24 only) | Matte and Grip (12 x 24 only) |
|---|---|---|---|
| Heritage Beige | 12 x 24, 24 x 24, 12 x 12 Mosaic A | 9mm | Matte |
| Passion Silver | 12 x 24, 24 x 24, 24 x 48, 12 x 12 Mosaic A | 9mm and 20mm (24 x 24 only) | Matte and Grip (12 x 24 only) |
| Vision Grey | 12 x 24, 24 x 24, 24 x 48, 12 x 12 Mosaic A | 9mm | Matte and Grip (12 x 24 only) |
| Liberty Black | 12 x 24, 24 x 24, 12 x 12 Mosaic A | 9mm | Matte |
TECHNICAL INFO
| Physical properties | Test ASTM | North American Standard | Results |
| Water absorption* | C373 | ≤ 0.5% | COMPLIANT |
|---|---|---|---|
| DCOF Average dynamic coefficient of friction** | BOT 3000 Test | ≥ 0.42 | ≥ 0.42 |
| Resistance to freeze/thaw cycles | C1026 | As reported | RESISTANT |
| Warpage (edge) | C485 | Warpage ± 0.4% or ± 0.05 in | COMPLIANT |
| Warpage (diagonal) | C485 | Warpage ± 0.4% or ± 0.07 in | COMPLIANT |
| Wedging | C502 | ± 0.25% or ± 0.03 in | COMPLIANT |
| Chemical resistance | C650 | As reported | UNAFFECTED |
| Breaking strength | C648 | 250 lbf or greater | COMPLIANT |
| Thickness | C499 | Range: 0.04 in | COMPLIANT |
